Data pattern selected by the DIP switch, which have the
following values:
?
?
?
01 : PRBS23
10 : PRBS7
High frequency pattern ( 1010 )
●
●
●
Receive side data to PRBS23 and PRBS7 checkers.
Error count values for PRBS23 and PRBS7 checkers
Lock signals for PRBS23 and PRBS7 checkers. This indicates that
the checker matched the receive pattern with the expected data
pattern.
Creating Your
Custom Data
The data_gen_checker_top_40bits.v is the top level for the data
generators and checkers. If you would like to create your own data
generators and checkers, replace this module with your own module. The
Generators and
Checkers
data output of this module should be connected to the tx_datain port
of the transceiver instantiation ( alt2gxb_6G_6250.v ) in the top-level
design_s2gx_top_level.v .
Altera Corporation
Getting Started User Guide
A–9
June 2006
Transceiver Signal Integrity Development Kit, Stratix II GX Edition
